SW12 price for HXGN-12 fixed type AC metal enclosed low voltage switchgear ring network cabinet

FOB Reference Price:Get Latest Price
US $500-10,000 / Pieces | 1 Piece/Pieces ring network cabinet (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Abbeycon
Model Number:
HXGN-12
Standard:
IEC/GB
CERTIFICATION:
Type test report/CESI/ CTQC/ISO9001
Main voltage range:
35KV/24KV/12KV/0.4KV
Main cabinet type:
KYN28/KYN61/GGD/XGN15/...
Rated capacity:
50,63,80,100,125,200,250,315,400,500,800,1000, 2000,2500A
Frequency:
50Hz or 60Hz
Advantage:
Best price & Best quality in China
CORPORATION::
EEPCO/KPLC/REA/PEC
Customized design:
Available
Product type:
ring network cabinet
Supply Ability
Supply Ability:
1500 Piece/Pieces per Month ring network cabinet
Packaging & Delivery
Packaging Details
ring network cabinet
1)1 plastic bag/set,1 wooden case/set
2)Special package required by clients.
Port
Ningbo, Shanghai, Wenzhou


ring network cabinet   ip67 momentary waterproof switch  hot selling china 3 phase distribution transformer

Product Description

price for HXGN-12 fixed type AC metal enclosed low voltage switchgear ring network cabinet

Operating environment:

1)Ambient temperature:-10°C-+40°C;

2)Altitude: high voltage ≤1000Meter, low voltage ≤2500Meter (technical department will design specially if exceeds);

3)Relative humidity:≤85%

4)Seismic intensity:≤ magnitude 8;

5Apply to the places have no fire,no explosion danger, no serious pollution,no chemical corrosion and no violent vibration.

  ring network cabinet

Executive standard:

GB7251         Low voltage complete set switchgear and control device

GB3906-2006    3.6kV~40.5kV AC metal enclosed switchgear and control device


  ring network cabinet

Technical parameter:



35KV high voltage switchgear technical parameter:

ring network cabinet



Parameter

Rated voltage

kV

40.5~33KV

Rated short time power frequency withstand voltage(1min)(1min)

kV

95

Rated lighting impulse withstand voltage

kV

185

Rated frequency

Hz

50

Rated current

A

630,1250,1600,2000,2500

Rated short circuit breaking current

kA

25

31.5

Rated peak value withstand current

kA

63

80

Rated control power

V

AC 110/220,DC 110/220

Dimension

KYN61-40.5

mm

1400*2800*2600

(width* depth* height)











 24KV high voltage switchgear technical parameter:

ring network cabinet



Parameter

Rated voltage

kV

24~15KV

Rated short time power frequency withstand voltage(1min)

kV

65

Rated lighting impulse withstand voltage

kV

125

Rated frequency

Hz

50

Rated current

A

630,1250,1600,2000,2500

Rated short circuit breaking current

kA

25

31.5

Rated peak value withstand current

kA

63

80

Rated control power

V

AC 110/220,DC 110/220

Dimension

KYN28A-24

mm

1000*1800*2450(width*depth*height)











 12KV high voltage switchgear technical parameter:

ring network cabinet



Parameter

Rated voltage

kV

3.6

7.2

12

Rated short time power frequency withstand voltage(1min)

kV

24

32

42

Rated lighting impulse withstand voltage

kV

40

60

75

Rated frequency

Hz

50

Rated current

A

630,1250,1600,2000,2500,3150,4000

Rated short circuit breaking current

kA

20

25

31.5

40

50

Rated peak value withstand current

kA

50

63

80

100

125

Rated control power

V

AC 110/220,DC 110/220

Dimension

(width*depth*height)

KYN28A-12

mm

(800/1000)*1500*2300

XGN2-12

mm

1100*1200*2650

HXGN-12

mm

(375/500)*900*1850





















 0.4KV low voltage switchgear technical parameter:





Parameter

Rated voltage

V

               400

690

Rated insulation voltage

V

690

1140

Rated impact withstand voltage

V

6000

10000

Rated working short circuit breaking ability

kA

18~100

10~75

Rated utmost short circuit breaking ability

kA

25~120

20~85

Rated frequency

Hz

50/60

Rated current

A

400,500,630,800,1000,1250,1600,2000,2500,3150,4000,5000,6300

Rated control power

V

AC 110/220/380,DC 110/220

Dimension

(Unit:mm)

MNS/GCS/GGD

width

400,600,800,1000,1200

depth

600,800,1000

height

2200





25

KYN28


IMG_1215

KYN61

We also supply the following series switchgears, click here for more details :
Rated votlage 40.5KV switchgear(for 33KV system)

Rated voltage 24KV switchgear(for 22KV,20KV, 15KVsystem)
Rated votlage 12KV switchgear(for 11KV,10KV,6.6KV system)

Rated voltage 0.4KV low voltage switchgear(380V,400V,433v,440V system)
XL-21 Power distribution box
MOTO Soft Start switchgear



Other Different kinds of High voltage power transmission products from us:



cable branch box.jpg

substation (2).jpg

  ring network cabinet

Our Services

 Trade terms:

1.Payment: 1) 30% in advance, balanced 70% to be paid before dispatch.       2) L/C

2.Port of loading: Ningbo,Wenzhou or Shanghai Port
3.Discounts: offered based on order quantities
4.Delivery time: 10-30 days according to order quantities.

Feedback:

       We WARMLY appreciate your positive feedback. We value our customers so much.If you have any problem, PLEASE FEEL FREE and DON'T HESITATE TO CONTACT US BY EMAIL IMMEDIATEDLY, we are always there to offer help.   ring network cabinet   hot selling china 3 phase distribution transformer

FAQ

Why Us?

1. Quality assurance: All the products will go through lots of tests carefully before dispatch: Raw material check, Winding test, Assemble test, Painting check, Nameplate check and routine tests.

2. Competitive production capacitymonthly production more than 1500 sets.

3. Manufactuer's priceFactory direct sale, most competitive price in China.

 ring network cabinet

Company Information

Our company:

       Our switchgears, substations, transformers sell well all over the world, and are exported to Ethiopia, Malaysia, Thailand, Kenya, Mozambique, Congo, Rwanda, Pakistan, South Africa and so on. We have won a good reputation among customers at home and abroad. Our price,quality and service are the most competitive in China.  ring network cabinet

       Welcome to our factory!  We are your best choice!



substation (1) - .jpg



Packaging & Shipping

 Packing:   ring network cabinet


substation (6).jpg

  ring network cabinet

Tips for Placing Order:

 The customer shall specify the following items:

♠ Primary circuit scheme and single line system diagram
 Secondary circuit schematic diagram, the wires shall be connected according to factory standard if customer has no requirement;
 Switchgear arrangement diagram, plan view of electric power substation.
 Detailed specification and parameter of electric element of each circuit;
 Surface colour of switchgear;
♠ Other requirements.
