M16 ON-ON 6 terminal TOP Quality light ATV DPDT marine switch

FOB Reference Price:Get Latest Price
US $0.1-2.5 / Pieces | 1 Piece/Pieces DPDT marine switch (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Abbeycon
Model Number:
5041
Max. Current:
20A
Max. Voltage:
250VAC
Mechanical Life:
50000 Cycles
Certificate:
CE,Rohs,CQC
IP Rating:
IP68
Function:
SPST,SPDT,DPST,DPDT...
Housing color:
Black/White
Lamp:
With or Without
Lamp color:
Red/Yellow/Green/Blue/Orange/White
Lamp voltage:
12V/24V/36V/110V/220V/others
Contact Resistance:
< 50MΩ
Insulation Resistance:
>1000MΩ
Product type:
DPDT marine switch
SupplyAbility
SupplyAbility:
990000000 Piece/Pieces per Week DPDT marine switch
Packaging & Delivery
Packaging Details
DPDT marine switch
1: Neutral packing : Blister inner box +carton
2: Upon customers' request, but the price is different with neutral packing
Port
Ningbo, Shanghai, Wenzhou


 DPDT marine switch

fuse base latching button switch

Product Description

ON-ON 6 terminal TOP Quality light ATV DPDT marine switch

Features:

PRODUCT TYPE

High quality Waterproof rocker switch

RATING:

10A 125V; 6A 250V;  20A 125V; 15A 250V

MECHANICAL LIFE:

>50000 CYCLES

ELECTRICAL LIFE:

>10000 CYCLES

WITHSTAND VOLTAGE:

>1500V/MINUTE

AMBIENT TEMPERATURE:

-10°C~+85°C

STORAGE TEMPERATURE:

-25°C~+85°C

MATERIAL:

Black or White UV resistant contoured plastic panel (High Quality Plastic)

PROCESS:

Be screen printing and laser carving

Standard Face surface size:

0.96' x 1.93'

Standard Cutout Dimensions:

0.83' x 1.46'

$

keywords$

05041 (2).jpg05041 (3).jpg05041 (1).jpg

Production Specification

(1) 100% test before shipment

(2) More than 50,000cycles life

(3) High current rating to 20 amps

(4) New style with rounded corners

(5) Lighted and non-lighted

(6) Maintain-action and momentary

     We can offer different kinds of symbols. All symbols are printed directly onto the switch face using modern high tech inks and printers to ensure long image life. we do not use stickers which will wear off in a very short time.

   The switch is rated at 20amp's, however in ALL case we recommend that you wire the accessory through a fused relay.

  We have many kinds of Marine rocker switches and panels, For more details, pls click here to visit our website. Thanks!    DPDT marine switch

Different kinds of Marine switches (Panels)and other switches from us:

Marine switch (9).jpg

Marine switch (1).jpg

6 (2).jpg

marine switch panel (38).jpg

fuse holder.jpg


waterproof switch (109).jpg

 DPDT marine switch



Packaging & Shipping
DPDT marine switch
Packing:

 1: Neutral packing :  Blister inner box bubble +carton

2: Upon customers' request, but the price is different with neutral packing

DPDT marine switchuse base

Shipping:

1.  DHL, EMS, TNT, Fedex, UPS and others international express.

2. By air or by sea. fuse base


DPDT marine switch
Our Services

 Payment term:

1.Payment: Paypal, Western Union, Aliexpress, T/T
2.Port of loading: Ningbo,Wenzhou or Shanghai Port
3.Discounts: offered based on order quantities
4.Delivery time: 3-30 days according to order quantities.

DPDT marine switchuse base
Feedback:

       We WARMLY appreciate your positive feedback. We value our customers so much.If you have any problem, PLEASE FEEL FREE and DON'T HESITATE TO CONTACT US BY EMAIL IMMEDIATEDLY, we are always there to offer help.DPDT marine switch

FAQ



Why Us?

1. Quality assurance: All the products will go through lots of tests carefully before dispatch
2. Competitive production capacity and fast shipping
3. Manufactuer's price: Factory direct sale, most competitive price.

DPDT marine switch

About Our products range:

        We manufacture and provide all kind of marine rocker switch,push button switch,tact switch, push switch,micro switch, toggle switch,fuse holder and others,With reliable quality assurance, prefect technical services and the best price, our products are sold well worldwide.

DPDT marine switch
Company Information

Our company Introduction:

1. Near 10-year experience in manufacturing of Marine rocker switches & panels and other electronic switches more than 8 year experience on export.

2. All of material passed ROHS and Reach certification.

3. Manufacturing process is comply with ISO9001.

4. We supply the good payment terms such as TT before shipment for our cutomers.

5. We can provide free samples for customer to test it.

6. Samples delivery time is within 24 hours.

7. The fast leading time is 3-10days( 1kpcs-100kpcs), 25-30days( 100kpcs-1000kpcs)

8. Factory info: Located in Wenzhou City, Zhejiang Province.

9. OEM Service and Buyer Label Offered.

10. Above 40 production lines.

11. Among 200 employees, including 12 R&D Engineer(s), 30 QC Technicians.

DPDT marine switch

cer (2).jpg

cer (1).jpg

 work (1).jpg

 DPDT marine switch

 Welcome to contact us for details:

ATTN: Power

Yueqing Abbeycon Electric Co., Ltd.

Tel: 0086-577-89008222  (24 hours' service)

Skype: cccmtth

E-mail: power(at)cnvcb.com

DPDT marine switch
  (Main products: 12V marine rocker switch, IP68 rocker switch, waterproof switch, good quality switch, illuminated switch, SPST, SPDT, DPDT rocker switch, double led switch, laser rocker switch, symbol rocker switch)
