BB136 Signal Chain Momentary contact block key switch /maintained IP40/IP65 push botton with key

FOB Reference Price:Get Latest Price
US $0.3-1 / Piece | 1 Piece/Pieces push botton with key (Min. Order)
Supply Ability:
9000000 Piece/Pieces per Month push botton with key
Port:
WENZHOU,NINGBO,SHANGHAI
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Abbeycon
Model Number:
LA165-A2-11Y
Protection Level:
IP40/IP65
Max. Current:
15A
Max. Voltage:
380V
Mounting hole diameter:
22mm
Material:
Plastic
Voltage:
DC6V to AC380V
Button color:
Red,green,yellow,blue,white,black
Operation type:
Momentary or Latching
Contact configuration:
1NO/1NC/2NO/2NC/1NO1NC or others
Illuminated:
LED available
Lamp voltage:
Customized
Button symbol:
Different available
Product type:
push botton with key
Packaging & Delivery
Packaging Details
push botton with key
1: Neutral packing : inner box +carton
2: Upon customers' request
Delivery Time
3 days after payment

  push botton with key  latching  LED switch button switch LED switch

Product Description

Signal Chain Momentary contact block key switch /maintained IP40/IP65 push botton with key

push botton with key

Specification:

Ambient temperature: -10°C~+85°C
Contact resistance: < 50MΩ
Insulation resistance: >500VDC 100MΩ Minute
Withstand voltage: >1000VAC, 1 Minute
Operating Temperature: -25°C~+85°C push botton with key

 Different kinds of products from us:





eywords$

Packaging & Shipping

   LED switch

Packing:

 1: Neutral packing : inner box +carton

2: Upon customers' request push botton with key

push botton with key

Shipping:

1.  DHL, EMS, TNT, Fedex, UPS and others international express.

2. By air or by sea.   push botton with key

    LED switch

Our Services

 Payment term:



1.Payment: Paypal, Western Union, Aliexpress, T/T,Alipay,Trade assurance, Credit card
2.Port of loading: Ningbo,Wenzhou or Shanghai Port
3.Discounts: offered based on order quantities
4.Delivery time: 3-30 days according to order quantities.    push botton with key

Feedback:

       We WARMLY appreciate your positive feedback. We value our customers so much.If you have any problem, PLEASE FEEL FREE and DON'T HESITATE TO CONTACT US BY EMAIL IMMEDIATEDLY, we are always there to offer help.   push botton with key

FAQ



Why Us?

1. Quality assurance: All the products will go through lots of tests carefully before dispatch
2. Competitive production capacity and fast shipping
3. Manufactuer's price: Factory direct sale, most competitive price.   push botton with key



About Push Button Switch:

    Push button switch is a sort of exclusive and high quality products in our factory and adopted superior raw materials from overseas through high speed CNC machine and relative production Dept designed for the strictly quality control management to manufacture.

     We have 5mm to 40mm diameter switch. Different colors of LED or buttons are available. Our switches are popular for use in elevators and kiosk applications, ticket dispensers and industrial-type applications.   push botton with key

Common description for push button switch:     Anti-vandal push button switch

(1) Momentary:

When you push switch and then move your finger, the actuator will back to the original position.  LED switch

(2)Latching:

When you press the button, it keeps pressed until you press again

(3) N.O.:

Normally Open circuit

(4) N.C.:

Normally Closed circuit

(5) SPST:

Single Pole Single Throw

(6) DPDT:

Double Pole Double Throw

(7) Contact:

The contact is a conducting part designed to be united by pressure to another conducting part for the purpose of carrying current.

(8) Silver plated gold :

Wonderful material with silver plated gold



Push Button Switches Applications:

1.Control contact
2.Control Panel
3.Mainframe computer switch
4.Motor
5.Machine tool
6.Relays
7.Electromagnetic starter
8.Various electrical     push botton with key

Company Information

Our company Introduction:    LED switch

1. Near 10-year experience in manufacturing Push button Switches, more than 8 years' experience on export.

2. All of material passed ROHS and Reach certification.

3. Manufacturing process is comply with ISO9001.

4. We supply the good payment terms such as TT before shipment for our cutomers.

5. We can provide free samples for customer to test it.

6. Samples delivery time is within 24 hours.

7. The fast leading time is 3-10days( 1kpcs-100kpcs), 25-30days( 100kpcs-1000kpcs)

8. Factory info: Located in Wenzhou City, Zhejiang Province.

9. OEM Service and Buyer Label Offered.

10. Above 48 production lines.

11. Among 350 employees, including 36 R&D Engineer(s), 45 QC Technicians.  push botton with key

 Welcome to contact us for details:    12m  LED switch m push button

ATTN: Power

Yueqing Abbeycon Electric Co., Ltd.

Tel: 0086-577-89008222  (24 hours' service)

Skype: cccmtth

Website: www.cnvcb.com

E-mail: power(at)cnvcb.com

E-shop:http://www.aliexpress.com/store/1679128 push botton with key
